Built-in Tuya smart module + 5.8G high-performance radar sensor.
Regular mode: APP control, dimming.
Radar sensing mode:

                  ◆◆Adjustable induction intensity High/Medium/Low

                  ◆◆Full brightness duration adjustable 5s-1h

                  ◆◆Unmanned mode: Low Consumption,Time duration adjustable

                  ◆◆Support light-sensing brightness Auto-check

                  ◆◆Induction synchronization within the group without additional wiring

Smart link,APP control Backlit Panel

ꁆ ꁇ

ꄴLast： ETL Surface Mount Panel Light

ꄲNext： UL ETL DLC PRODUCTS

Product description

1x4	Power	Input Voltage	Luminous	Lumen	CCT	Size	CIR	PF	Warranty
14FT20W-H-XX	20W	AC120-277V/ 120-347V	2600Lm	125Lm/W	3500K 4000K 5000K	*3031213mm**	＞80	0.9	5years
14FT24W-H-XX	24W		3120Lm
14FT28W-H-XX	28W		3640Lm
14FT30W-H-XX	30W		3900Lm
14FT32W-H-XX	32W		4160Lm
14FT36W-H-XX	36W		4680Lm
14FT40W-H-XX	40W		5200Lm
14FT20W-L-XX	20W		2200Lm	110Lm/W	3500K 4000K 5000K
14FT24W-L-XX	24W		2640Lm
14FT28W-L-XX	28W		3080Lm
14FT30W-L-XX	30W		3300Lm
14FT32W-L-XX	32W		3520Lm
14FT36W-L-XX	36W		3960Lm
14FT40W-L-XX	40W		4400Lm
2x2	Power	Input Voltage	Luminous	Lumen	CCT	Size	CIR	PF	Warranty
22FT20W-H-XX	20W	AC120-277V/ 120-347V	2600Lm	125Lm/W	3500K 4000K 5000K	*603603mm**	＞80	0.9	5years
22FT24W-H-XX	24W		3120Lm
22FT28W-H-XX	28W		3640Lm
22FT30W-H-XX	30W		3900Lm
22FT32W-H-XX	32W		4160Lm
22FT36W-H-XX	36W		4680Lm
22FT40W-H-XX	40W		5200Lm
22FT20W-L-XX	20W		2200Lm	110Lm/W	3500K 4000K 5000K
22FT24W-L-XX	24W		2640Lm
22FT28W-L-XX	28W		3080Lm
22FT30W-L-XX	30W		3300Lm
22FT32W-L-XX	32W		3520Lm
22FT36W-L-XX	36W		3960Lm
22FT40W-L-XX	40W		4400Lm

2x4	Power	Input Voltage	Luminous	Lumen	CCT	Size	CIR	PF	Warranty
24FT28W-H-XX	28W	AC120-277V/ 120-347V	3640Lm	125Lm/W	3500K 4000K 5000K	*6031213mm**	＞80	0.9	5years
24FT30W-H-XX	30W		3900Lm
24FT32W-H-XX	32W		4160Lm
24FT36W-H-XX	36W		4680Lm
24FT40W-H-XX	40W		5200Lm
24FT45W-H-XX	45W		5850Lm
24FT50W-H-XX	50W		6500Lm
24FT28W-L-XX	28W		3080Lm	110Lm/W	3500K 4000K 5000K
24FT30W-L-XX	30W		3300Lm
24FT32W-L-XX	32W		3520Lm
24FT36W-L-XX	36W		3960Lm
24FT40W-L-XX	40W		4400Lm
24FT45W-L-XX	45W		4950Lm
24FT50W-L-XX	50W		5500Lm
